FEATURES• Two way shut-off valves for the control air, inert gas, water, oil and other gases/
liquids compatible with the sealing material used
• Valves do not require a minimum operating pressure
• All products are covered by Pressure Equipment Directive 97/23/EC and are suitable
for group 1 and 2 fluids
• The solenoid valves satisfy all relevant EC directives
STANDARD VOLTAGES
DC (=) : 24V
AC (~) : 24V/50 - 22V/50, 24V/60 - 100V/50, 110V/60 - 110V/50,
120V/60 - 115V/60 - 115~120V/50 - 208V/60 - 220V/50,
240V/60 - 230~240V/50
● Available Express
(1) TPL 25848: valve with 3-solenoid for normally open > 0 bar and closed at 0 bar and with special body and high shock clip
(2) DC only
(3) AC only
(4) VCEF can be mounted in 4 directions & 3 conduit sizes
(5) 0.3 bar on Air; 0.0 bar on Water
(6) TPL 19880: special DZR brass body & bonnet
