FEATURES• Hot water service to 210 psi differential @ 210°F;
Steam sevice to 125 psi differential @ 353°F
• Specify these valves for the high-temperature applications found in laundries,
molding, steam atomization, sterilizers, autoclaves, and many others
• Series 8263: direct acting miniature valves
• Series 8267: direct acting straight-through, self-cleaning design
• Series 8210/8220: pilot operated diaphragm valves
• Series 8220: pilot operated diaphragm and piston valves; floating PTFE
diaphragms or stainless steel pistons with EPDM or PTFE discs, available in both
AC & DC voltages
• Series 8221: slow-closing, anti-water hammer design
• Series 8222: pilot operated diaphragm and piston valves.
Y-body floating piston design
STANDARD VOLTAGES
AC (~) : 110V - 120V - 220V - 240V / 50 - 60 Hz
