For splitting flow into two directions, but not for sealing off in either direction.

Specifications

• Connection Size: 2 "
• Connection Type: Female NPT
• Body Style: 3 Way
• Body Material: Steel
• Option Available for NACE MR0175 compliance or certification.
• Trim Size: 1.25 "
• Process Fluid: Liquid and Gas
• Max. Working Pressure: 3000 psig
• Max. Set Point Pressure: 3000 psig
• Operation: Pneumatic
• 100% Open Cv of Bottom Port: 10.5
• Catalog Page: E4:20.1
• Face-to-Face Length: 7.31 "
• Repair Kit P/N: RFG
