伺服驱动器
| 规格 | 型号 | |
|---|---|---|
| 单相AC100V | portant;"> 50W | R88D-GNA5L-ML2 |
| portant;"> 100W | R88D-GN01L-ML2 | |
| portant;"> 200W | R88D-GN02L-ML2 | |
| portant;"> 400W | R88D-GN04L-ML2 | |
| 单相AC200V | portant;"> 50W | R88D-GN01H-ML2 |
| portant;"> 100W | ||
| portant;"> 200W | R88D-GN02H-ML2 | |
| portant;"> 400W | R88D-GN04H-ML2 | |
| 单相/三相AC200V | portant;"> 750W | R88D-GN08H-ML2 |
| portant;"> 1kW | R88D-GN10H-ML2 | |
| portant;"> 900W | R88D-GN15H-ML2 | |
| portant;"> 1kW | ||
| portant;"> 1.5kW | ||
| 三相AC200V | portant;"> 2kW | R88D-GN20H-ML2 |
| portant;"> 2kW | R88D-GN30H-ML2 | |
| portant;"> 3kW | ||
| portant;"> 3kW | R88D-GN50H-ML2 | |
| portant;"> 4kW | ||
| portant;"> 4.5kW | ||
| portant;"> 5kW | ||
| portant;"> 6kW | R88D-GN75H-ML2 | |
| portant;"> 7.5kW | ||
伺服电机
【INC】圆柱型伺服电机用(3,000r/min)
| 规格 | 型号 | |||
|---|---|---|---|---|
| 直轴 | 带按键和阀门的直轴 | |||
| 不带制动器 | portant;"> 100V | portant;"> 50W | R88M-G05030H | R88M-G05030H-S2 |
| portant;"> 100W | R88M-G10030L | R88M-G10030L-S2 | ||
| portant;"> 200W | R88M-G20030L | R88M-G20030L-S2 | ||
| portant;"> 400W | R88M-G40030L | R88M-G40030L-S2 | ||
| portant;"> 200V | portant;"> 50W | R88M-G05030H | R88M-G05030H-S2 | |
| portant;"> 100W | R88M-G10030H | R88M-G10030H-S2 | ||
| portant;"> 200W | R88M-G20030H | R88M-G20030H-S2 | ||
| portant;"> 400W | R88M-G40030H | R88M-G40030H-S2 | ||
| portant;"> 750W | R88M-G75030H | R88M-G75030H-S2 | ||
| 带制动器 | portant;"> 100V | portant;"> 50W | R88M-G05030H-B | R88M-G05030H-BS2 |
| portant;"> 100W | R88M-G10030L-B | R88M-G10030L-BS2 | ||
| portant;"> 200W | R88M-G20030L-B | R88M-G20030L-BS2 | ||
| portant;"> 400W | R88M-G40030L-B | R88M-G40030L-BS2 | ||
| portant;"> 200V | portant;"> 50W | R88M-G05030H-B | R88M-G05030H-BS2 | |
| portant;"> 100W | R88M-G10030H-B | R88M-G10030H-BS2 | ||
| portant;"> 200W | R88M-G20030H-B | R88M-G20030H-BS2 | ||
| portant;"> 400W | R88M-G40030H-B | R88M-G40030H-BS2 | ||
| portant;"> 750W | R88M-G75030H-B | R88M-G75030H-BS2 | ||
注： 可选择带油封的型号。
【ABS/INC】圆柱型伺服电机用(3,000r/min)
| 规格 | 型号 | |||
|---|---|---|---|---|
| 直轴 | 带按键和阀门的直轴 | |||
| 不带制动器 | portant;"> 100V | portant;"> 50W | R88M-G05030T | R88M-G05030T-S2 |
| portant;"> 100W | R88M-G10030S | R88M-G10030S-S2 | ||
| portant;"> 200W | R88M-G20030S | R88M-G20030S-S2 | ||
| portant;"> 400W | R88M-G40030S | R88M-G40030S-S2 | ||
| portant;"> 200V | portant;"> 50W | R88M-G05030T | R88M-G05030T-S2 | |
| portant;"> 100W | R88M-G10030T | R88M-G10030T-S2 | ||
| portant;"> 200W | R88M-G20030T | R88M-G20030T-S2 | ||
| portant;"> 400W | R88M-G40030T | R88M-G40030T-S2 | ||
| portant;"> 750W | R88M-G75030T | R88M-G75030T-S2 | ||
| portant;"> 1kW | R88M-G1K030T | R88M-G1K030T-S2 | ||
| portant;"> 1.5kW | R88M-G1K530T | R88M-G1K530T-S2 | ||
| portant;"> 2kW | R88M-G2K030T | R88M-G2K030T-S2 | ||
| portant;"> 3kW | R88M-G3K030T | R88M-G3K030T-S2 | ||
| portant;"> 4kW | R88M-G4K030T | R88M-G4K030T-S2 | ||
| portant;"> 5kW | R88M-G5K030T | R88M-G5K030T-S2 | ||
| 带制动器 | portant;"> 100V | portant;"> 50W | R88M-G05030T-B | R88M-G05030T-BS2 |
| portant;"> 100W | R88M-G10030S-B | R88M-G10030S-BS2 | ||
| portant;"> 200W | R88M-G20030S-B | R88M-G20030S-BS2 | ||
| portant;"> 400W | R88M-G40030S-B | R88M-G40030S-BS2 | ||
| portant;"> 200V | portant;"> 50W | R88M-G05030T-B | R88M-G05030T-BS2 | |
| portant;"> 100W | R88M-G10030T-B | R88M-G10030T-BS2 | ||
| portant;"> 200W | R88M-G20030T-B | R88M-G20030T-BS2 | ||
| portant;"> 400W | R88M-G40030T-B | R88M-G40030T-BS2 | ||
| portant;"> 750W | R88M-G75030T-B | R88M-G75030T-BS2 | ||
| portant;"> 1kW | R88M-G1K030T-B | R88M-G1K030T-BS2 | ||
| portant;"> 1.5kW | R88M-G1K530T-B | R88M-G1K530T-BS2 | ||
| portant;"> 2kW | R88M-G2K030T-B | R88M-G2K030T-BS2 | ||
| portant;"> 3kW | R88M-G3K030T-B | R88M-G3K030T-BS2 | ||
| portant;"> 4kW | R88M-G4K030T-B | R88M-G4K030T-BS2 | ||
| portant;"> 5kW | R88M-G5K030T-B | R88M-G5K030T-BS2 | ||
注： 可选择带油封的型号。
【INC】扁平型伺服电机(3,000r/min)
| 规格 | 型号 | |||
|---|---|---|---|---|
| 直轴 | 按键和阀门的直轴 | |||
| 不带制动器 | 100V | portant;"> 100W | R88M-GP10030L | R88M-GP10030L-S2 |
| portant;"> 200W | R88M-GP20030L | R88M-GP20030L-S2 | ||
| portant;"> 400W | R88M-GP40030L | R88M-GP40030L-S2 | ||
| 200V | portant;"> 100W | R88M-GP10030H | R88M-GP10030H-S2 | |
| portant;"> 200W | R88M-GP20030H | R88M-GP20030H-S2 | ||
| portant;"> 400W | R88M-GP40030H | R88M-GP40030H-S2 | ||
| 带制动器 | 100V | portant;"> 100W | R88M-GP10030L-B | R88M-GP10030L-BS2 |
| portant;"> 200W | R88M-GP20030L-B | R88M-GP20030L-BS2 | ||
| portant;"> 400W | R88M-GP40030L-B | R88M-GP40030L-BS2 | ||
| 200V | portant;"> 100W | R88M-GP10030H-B | R88M-GP10030H-BS2 | |
| portant;"> 200W | R88M-GP20030H-B | R88M-GP20030H-BS2 | ||
| portant;"> 400W | R88M-GP40030H-B | R88M-GP40030H-BS2 | ||
